Glass Door Pull Handle
AHL-55
Pull Handle with Lock (Round Ø 35)
1500 mm round pull handle with built-in lock, for main glass entrance doors.
- Overall 1500 mm
- Lock 300 mm from top
- Ø 20 / Ø 15 standoffs
| Code | Size / option | Price |
|---|---|---|
| AHL-55 | 35×1500 | ₹17,500 |
List price per piece, excluding GST and freight. Size = diameter × hole-to-hole × overall length, in mm.
Available in satin steel, Black, Rose Gold and Gold. Coloured finish price on request.
Using AHL-55
How and where it is used
Pull handles for glass and wooden doors, in H, D and offset shapes, SS 202 and SS 304, plain or two-tone.
How it is installed
- Drill holes in the glass at the handle's hole-to-hole distance before toughening.
- Fix with the bolts, sleeves and washers supplied; back-to-back on both faces of the door.
Where it is used
- Glass entrance doors
- Office and shop doors
- Wooden and aluminium doors
Choosing tips
- Pick handle length to suit door height; 450–600 mm suits most entrance doors.
- SS 304 resists rust better outdoors and near the sea.
- AHL-55 adds a floor lock built into the handle for main entrances.
Technical drawing
Dimensions & glass preparation
Dimensions in mm. Confirm glass cut-outs with our team before toughening.
