Canopy Fitting
ACF-07
Canopy Rod with Thread Ø 16 mm (SS 316)
16 mm threaded SS 316 rod, 2 m or 3 m.
- SS 316
| Code | Size / option | Price |
|---|---|---|
| 2 m | ₹3,840 | |
| 3 m | ₹5,660 |
List price per piece, excluding GST and freight.
Using ACF-07
How and where it is used
Canopy fittings hold a glass canopy above an entrance with stainless rods or wire rope. SS 316 for outdoor use.
How it is installed
- Fix the wall connectors and glass connectors at the planned points.
- Join them with the 16 mm threaded rod or 12 mm wire rope with its locking system.
- Adjust the rod or rope to level the glass.
Where it is used
- Building and shop entrance canopies
- Balcony and terrace covers
- Car porch glass canopies
Choosing tips
- Rod systems look clean and rigid; wire rope suits longer spans.
- Use laminated toughened glass for canopies overhead.
